Tatu Marchesan 10020 GASPM EHD
The Model 9017 GASPM HD is specifically designed to meet the extreme conditions in construction, road building, deep tillage, tilling new ground and recently deforested land.
Standard Features
- Tatu oil bath bearing assemblies with tapered roller blade and duo-cone seals
- 1/2" x 5" x 10" gang carriers, reinforced through two welded "U" profile
- 2 1/2" round heat treated alloy steel gang axles
- Cast spacer spools
- Heat treated boron steel disk blades, notched front and rear
- Heavy duty disk blade scrapers
- Stabilizer bar front and rear disk gangs leveling
- Preforated offset bar to allow lateral adjustments under varying draft conditions
- Box type construction drawbar with standard drawbar plates
- Adjustable gang axles up to 42 degrees
- Removable bushings on articulated points
Optional Features
Specifications
| Number of Disk Blades | Working Width
ft. in. (mm) | Disk Blade Dimensions | Disk Blade Spacing | Weigth per Disk
lbs (kg) | Approx Net Weight*
lbs (kg) | Tractor Drawbar Horsepower** | | 10 | 5' 10"
(1,800) | 36" x 12mm | | 673 (305) | 6,733 (3,054) | 130 - 140 | | 12 | 7' 3"
(2,200) | 38" x 12mm | 17 5/16" | 625 (283) | 7,500 (3,402) | 145 - 155 | | 16 | 10' 2"
(3,100) | and | (440mm) | 660 (299) | 10,553 (4,787) | 205 - 220 | | 20 | 13' 1"
(4,000) | 40" x 12mm | | 660 (299) | 13,198 (5,986) | 260 - 280 | *Approximate Net Weight with 36" x 12mm disk blades
**Please note that the tractor drawbar horsepower are suggested ranges and vary according to soil conditions and weight |
|
Resources
This product was added to our catalog on Saturday 09 December, 2006.
TatuDiskHarrows.com Product Reference Model Number: 10020 GASPM EHD
